512 Flash Memory Chip Intelligent Test System
Product Specification
1.Flash memory chip intelligent test system HD-512-NAND is a comprehensive flash memory test system that can customize the test plan and support parallel testing of various types of flash memory particles. 64 types, the maximum number of flash memory particles in parallel testing can reach 512.
Flash memory chip intelligent test system YC-512-NAND supports multiple test patterns and custom test parameter functions, and can provide one-click basic test process and high-level test process with high flexibility, not only can realize the remaining life of flash memory particles, actual measurement , data retention and read interference and other functional tests can also help users verify the reliability status of flash memory particles. After the test is completed, the test report can be easily and quickly exported with one key, providing customers with the most intuitive and accurate graphical test data. Provide the most intuitive data reference for the grade classification and application of flash memory particles, and realize intelligent classification based on the quality inspection results of flash memory particles.
※ The test basis complies with JEDEC Stand No.218: Solid State Technology Association B-2016 Solid-State Drive(SSD) Requirements And Endurance Test Motho;
※ The test basis complies with JEDEC Standard No.47 NVCE: Solid State Technology Association Stress-Test-Driven Qualification of Integrated Circuits;
※ The design specifications of the test board meet the requirements of the industrial-grade test temperature environment;
Information
Inner box size | W760×D400×H890mm |
Outer box size | W1870×D890×H1830mm |
volume | 270L |
Opening method | Single door (right open) |
cooling method | air-cooled |
weight | about 950KG |
power supply | AC 380V About 7.5 KW |
Control System
Display | Color LCD display |
Operation mode | Program mode, fixed value mode |
Setting | Chinese and English menu (optional), touch screen input |
Setting range | Temperature: Adjust according to the temperature working range of the equipment (upper limit +5°C, lower limit -5°C) |
display resolution | Temperature: 0.01°C Time: 0.01min |
control method | BTC balanced temperature control method + DCC (intelligent cooling control) + DEC (intelligent electrical control) (temperature test equipment) BTHC balanced temperature and humidity control method + DCC (intelligent cooling control) + DEC (intelligent electrical control) (temperature and humidity test equipment) |
Curve record function | It has RAM with battery protection, which can save the set value, sampling value and sampling time of the device; the maximum recording time is 350 days (when the sampling period is 1.5min) |
Accessory function | Fault alarm and cause, processing prompt function Power-off protection function Upper and lower limit temperature protection function Calendar timing function (automatic start and automatic stop operation) self-diagnosis function |
