stiffness bending tester
stiffness bending tester
Product introduction
stiffness
bending tester is mainly determines the ductility or the strength of a materialby bending the material over a given radius.
Standard Features：
Item | Description |
Max. Force | 2000 kg (20KN) |
Load cell | Germany brand load cell for high accuracy |
Control system | PC with windows 7 system |
Motor | Panasonic servo motor w/ DC variable speed drive system, high-precision mechanical ball screw rod |
Force reading | kgf, Ibf, N, KN, T etc |
Stoke | 1100mm including fixture |
Load cell Resolution | 1/250,000 |
Load Precision | within ±0.5% |
Test speed | 0.01~500mm/min (adjustable) |
Software | TM 2101 |
Curves display | Load- elongation, Elongation-time, Time-elongation, Stress-strain |
Data display | Max. force, speed, sample information, strength(Kpa, Mpa, N/mm, N/mm2) etc… |
Safety features | E-Stop Over-load protection Upper and lower limit switches Load sensor with automatic retreat |
Features：
1. Deformation under defined
load: Test deformation under defined load of tested sample
2. Load under defined
deformation: Test load under defined deformation of tested sample
3. Software can issue report
with results for max. force, elongation, tensile strength, peel strength, tear
strength, compression strength, etc.
4. Stiffness bending tester can do
different test as per customer requirement such as peel test, tear test,
compression test, bend test with different clamps.
Applications：
stiffness bending tester is widely determine the bending resistance of paper, paperboard, plastic film, medical tubing, and wire,etc.
Standard：
the standard of stiffness
bending tester including but not limited
GB/T
2653-2008 ,ASTM
E290-09、GB/T 232-1999、ISO 7438-2005、
JIS Z 2248-2006、EN ISO
7438-2005
