Battery Pack Seawater Immersion Tester
Battery Pack Seawater Immersion Tester
FEATURES
1. Configure seawater solution: configure with seawater concentration detector;
2. Soaking box size (W*D*H): 3500*2500*1500mm;
3. Test space: up to 3000*2000*1000mm sample normal test;
4. Test load: 1500kg or more;
5. Water tank carrying weight: ≥20Ton.
Standard Parameters
Model | HD-H216 | |
Water tank composition | Exterior brick + interior glass steel | Fixed |
External stainless steel + internal FRP | Movable | |
Water tank size | Internal dimension(W*D*H) | 3430*2430*1470mm |
External dimension(W*D*H) | 3500*2500*1700mm | |
Basket size(W*D*H) | 3200*2200*500mm | |
Observation port | 300*500mm | |
Water treatment | Water softener | |
Salinity ratio | Automatic + brine configuration box / manual | |
Drainage | automatic / manual | |
Sport mode | automatic / manual | |
Control System | Live touch screen + remote PC | |
Equipment structure | Mobile console + open type | |
Alarm function | Foldable three-color lamp, abnormal operation alarm | |
Protective function | Water level overrun protection | |
Ground bearing | Requires solid ground, bearing 1T/m3 | |
Power supply | AC380V | |
TEST STANDARD
UL 1642:2012; UL 2054:2012; IEC 62281:2004; UN 38.3
