UV aging test machine

1. Product description

UV aging test machine which as a kind of environment test chamber can simulate the most important ultraviolet light in the sun, reproduction of light caused by the aging of the physical properties of materials

USAGE:

Environmental Sun Rain Spray Accelerated Weather Testing / UV Testing Machine is mainly used in paint and ink paint, resins, plastics, printing and packaging, aluminum, adhesives, car and motorcycle industry, cosmetics, metals, electronics, electroplating, medicine and other fields. Conform ASTMG53-77 specification GB ﹑ GJB MIL CNS ﹑ ASTM JIS IEC ﹑ Fed Test AATCC DIN ﹑ BS﹑ SAE standards.

2. Technical parameters:

Studio Size	400W×1140D×390Hmm
Outside dimension	500W×1300D×1360Hmm
Materials	Inside and Outside SUS#304 stainless steel
Temperature range	RT+10~70°C
Temperature uniformity	±2°C
Temperature fluctuation	±0.5°C
Temperature control	PID SSR control
Humidity range:	≥90%RH
Controller	Korean TEMI 880 programmable controller
Control mode	Balance temperature humidity control (BTHC)
Test cycle setting	Illumination, condensation and water spray test cycle is programmable
Lamp power	40W/Piece
Distance from sample to lamp	50±2mm (adjustable)
Centre distance between the lamp	70mm
Irradiance	1.0W/cm2
Wavelength ultraviolet light	UV-A: 315-400nm; UV-B: 280-315nm (8pcs, 1600h lifetime)
Effective irradiation areas	640×1140mm
Irradiation black panel temperature	50°C~70°C
Standard Specimen Size	75×150mm or 75×3000mm (special specitications to be described in the contact)
Required water depth for water channel	25mm, automatically control
Testing time	0~999H, adjustable
Power	220V/50Hz /±10% 5KW
Protection system	Overload short circuit protection, over temperature protection, water lackin

Chamber Structure:

The inner bladder of the chamber is made of imported high-class stainless steel plate while the outer bladder is made of SUS 304 steel plate.

The heating mode adopts inner bladder trough type heating with its rapid temperature rise and even temperature distribution.

Design criteria:

(1) ASTM D4587: Standard Practice for Fluorescent UV-Condensation Exposures of Paint and Related Coatings

(2) ASTM D4799: Standard Practice for Accelerated Weathering Test Conditions and Procedures for Bituminous Materials (Fluorescent UV, Water Spray, and Condensation Method)

(3) ISO 4892-1: Plastics – Methods of Exposure to Laboratory Light Sources – Part 1: General guidance

(4) ISO 4892-3: Plastics - Methods of Exposure to Laboratory Light Sources - Part 3: Fluorescent UV Lamps

(5) ASTM D4329: Standard Practice for Fluorescent UV Exposure of Plastics

(6) AATCC TM186: Weather Resistance: UV Light and Moisture Exposure

(7) ASTM D5208: Standard Practice for Fluorescent Ultraviolet (UV) Exposure of Photodegradable Plastics

(8) IEC 61345: UV Test for Photovaltalic (PV) Modules

Experimental Methods
Method 1: 8 hours of ultraviolet light, a test temperature of 60 degrees, 4 hours condensation, the test temperature of 50 degrees
Method 2: 4 hours of ultraviolet light, a test temperature of 60 degrees, 4 hours condensation, the test temperature of 50 degrees
Method 3: 8 hours of ultraviolet light, a test temperature of 50 degrees, 4 hours condensation, the test temperature of 45 degrees
Method 4: four hours of ultraviolet light, the test temperature is 50 degrees, condensing 4 hours, the test temperature of 45 degrees
Method 5: 1000 hours of ultraviolet light, the test temperature of 60 degrees
Method 6: UV light 300 hours, the test temperature of 80 degrees

Poduct image:

UV aging test machine
