Konica Minolta Colorimeter HD-X003-2

Colorimeter HD-X003-2（CR400）

The new Konica Minolta "CR-400", "CR-410" colorimeter can be measured by measuring the head monomer, which has high accuracy and are versatile and easy to operate.

Type ---- reflective color measurement

Main use: paint, rubber, plastics, printing, fiber, dyeing, food, agriculture, forestry, fisheries, ceramics, nitrogen products, residential construction, medical and academic fields

Colorimeter Products

Renowned color colorimeter series - more powerful and diverse

Colorimeter from the famous series, more powerful and diverse.

New colorimeter CR-400 is a widely recognized and acclaimed CR-100, CR-200, CR-300 series successor. It has a lot of additional features, more versatile, but fully retained the all-optical characteristics, so make sure you can exchange data with the previous model. CR-400 measuring area of 8mm, suitable for measuring various industries reflected color and color difference. It can meet the ingredients, food, raw materials, finished goods, drugs and dermatology, and many other applications

Colorimeter Main Specifications

Name colorimeter measuring head

Model CR-400 measuring head CR-410 measuring head

Lighting / receiving optical system d / 0 (diffuse illumination light perpendicular manner; specular component included)

(With JIS Z 8722 standard; including regular reflection light) large area lighting vertical light way; specular component included)

Light sub-prime silicon photocell (6)

Display range Y: 0.01% ~ 160.00% (reflectance)

Measuring light source pulsed xenon arc lamp

Measuring time 1 s

The shortest interval of three seconds can be determined

Measurable frequency about 800 times (my company under specified conditions)

Measurement / illumination area Φ8mm / Φ11mmΦ50mm/Φ53mm

Repeatability standard deviation ΔE * ab 0.07 or less (in 10 seconds after white calibration measured 30 times at intervals)

Instrument error ΔE * ab: 0.6 or less

BCRA Series II 12 colors mean ΔE * ab: 0.8 or less

BCRA Series II 12 colors mean

Viewing conditions CIE2 ° approximate color vision functions such as:

Observation light source * C, D65

Display * color values, color values, pass / warning / fail

Eligibility determination * color difference threshold (box / oval critical)

Chromaticity diagram / table color value * XYZ, Yxy, L * a * b *, search Lab, L * C * h, Husserl (only illuminant C), CMC (l: c), CIE1994, Lab99, LCh99 , CIE2000, CIE WI / Tw (only illuminant D65), WI ASTM E313 (only illuminant C), YI ASTM D1925 (only illuminant C), YI ASTM E313 (only illuminant C), users retrieve (can register up to 6 from a computer )

Use language operating buttons: English

* LCD: English (default), German, French, Italian, Spanish, Japanese

Save Data Quantity 1000 data (measuring head and data processor save different content)

Color reference color 100

Correction Channel * 20 channels (ch00: white calibration, ch01 ~ ch19: Any correction)

Backlit dot matrix LCD display (15 characters × 9 lines + icon displays a row)

Interfaces RS-232 standard (connection data processor / PC)

* Baud rate: 4800,9600,19200 (bps); factory-set to 9600bps

Power 4 AAA-size alkaline or Ni-MH batteries

Or the AC adapter AC-A17 AC120V 50-60Hz 0.4A (for North America and Japan) AC230V 50-60Hz 0.4A (for countries or regions outside of North America)

Dimensions (W × H × D) mm102 × 244 × 63mm

Weight approx 550g

(Including 4 AAA batteries, excluding RS-232C cable) approx 570g

(Including 4 AAA batteries, excluding RS-232C cable)

Operating temperature / humidity range 0 ~ 40 ° C, relative humidity 85% or less with no condensation

Storage temperature / humidity range -20 ~ 40 ° C, relative humidity 85% or less with no condensation

Other LCD backlight ON / OFF function (ON Time: operation key operation or measurement light 30 seconds)

Standard accessories White Calibration Plate CR-A43, cover CR-A72, tightening clamp CR-A73, AC Adapter AC-A17, 4 AAA batteries White Calibration Plate CR-A44, cover CR-A72, CR-tightening clamp A73, AC Adapter AC-A17, 4 AAA batteries
