Insulation resistance tester

Introduction：

Insulation resistance tester is a test instrument insulating properties of a testing of electronic components ,  machine ,  material ,  has the characteristics of fast test speed ,  stable and reliable ,  convenient operation etc .  .  Suitable for factory production line ,  quality inspection departments and laboratory test requirements .

Parameters :

Measure the voltage range of 10V-1000V to DC

The voltage resolution 1V

Voltage accuracy 3%

Resistance measurement range of 10K Ω -10^6M

Resistance measurement accuracy ± 2% ± 3% ± 5% ± 15% set according to the test voltage ,  resistance

Resistance limit set 10M Ω -10^6M

Resistance limit set 10M Ω -10^6M

Communication interface PLC interface ,  RS232C  ( optional )

Working temperature 0 ℃ -40 ℃ ,  ≤ 85%RH

Power requirements 198V-242V AC ,  47 . 5Hz-52 . 5Hz

Dimensions 326 x 102 x 345  ( mm )

Weight 6kg
