Ahensive Tape Climatic chamber
Product Description:
Climatic chamber is mainly to test the adhesive resistance property and the holding adhesive property of the pressure sensitive tape. The static loading test: paste the tape to the testing board, timing for a period, and evaluate the halding adhsion property according to the distance the tape slips or the time it takes. This machine can simulate high temperature and high humidity/high temperature and low humidity/low temperature and high humidity/low temperature and low humidity conditions. High standard procedure and control system are attached for good testing environment.
APPLICATIONS:
- To simulate test environment with different temperature and humidity
- Cyclic test includes climatic conditions: holding test, cooling-off test, heating-up test, moistening test and drying test…
- Cable port with flexible silicone plug for cable routing to provide the condition of test unit under operation
-
Uncover test unit weakness in a short-term test with accelerated time effect
Main Technical Parameters:
Model
HD-E702-100-4
Internal dimension(W*D*H)
400*500*500mm
External dimension(W*D*H)
900*1070*1400mm
Temperature range
-40~+150℃
Temperature Accuracy
±1℃
Humidity range
20~98%R.H. (Refer Image below)
Humidity accuracy
±3%R.H
Cooling speed
1℃/min in average (without loading)
Heating speed
3℃/min in average (without loading)
Internal chamber material
SUS#304 stainless steel, mirror finished
External chamber material
Stainless steel with paint spray
Cooling method
Air cooling
Controller
LCD touch screen, programmable control temperature and humidity
Can set different parameter for cyclic test
Insulation material
50mm high density rigid Polyurethane foam
Heater
Explosion-proof type SUS#304 stainless steel fins radiator pipe heater
Compressor
France Tecumseh compressor
Lighting
Heat resistance
Temperature sensor
PT-100 dry and wet bulb sensor
Observation window
Tempered glass
Testing hole
Diameter 50mm, for cable routing
Sample tray
SUS#304 stainless steel, 2pcs
